8 Cores Patch Panel Wall Mounted Terminal Box
Type:
Indoor
Installation Way:
Wall mounted
Distribution:
Steel tube PLC SplitterNo PLC Splitter
Max Capacity:
8 Cores
Online consultationSend email
Product list FAQ Reviews Resources
New
SS-8Cores-127 8 cores fiber patch panel can hold up to 8 subscribers. It is used as a termination point for the drop cable to connect with patch cable in FTTH indoor application. It integrates fiber splicing, termination, storage, and cable connection in one solid protection box.
BESTSELLERS
PRODUCT SPECIFICATIONS
  • Water-proof design with IP-45 Protection level.
  • Integrated with splice cassette and cable management rods.
  • Manage fibers in a reasonable fiber radius condition.
  • Easy to maintain and extend the capacity.
  • Fiber bend radius control more than 40mm.
  • Suitable for the fusion splice or mechanical splice.
  • Efficient cable management.
  • 8 ports cable entrance for drop cable.
Index Specifications
Size ( L*W*H) 220*140*53MM
Application 3.0 x 2.0 mm drop cable or indoor cable
Fiber diameter 125μm ( G652D & G657A )
Tight cladding diameter 250μm & 900μm
Mode of application Single mode & duplex mode
Tensile strength >50 N
End-use temperature -40~+85℃
Adaptor SC Simplex or LC Duplex
Insertion loss ≤0.2dB  ( 1310nm & 1550nm)
Output 8 SC / FC
Max Capacity 8 cores

SCOPE OF APPLICATION
PRODUCT PACKAGING
TECHNICAL DOCUMENT
COMPATIBLE
OEM&ODM SUPPORTED
  • OEM Manufacturer
    SEESUO provides tailored OEM productsbased on clients' designs and specs
  • ODM Manufacturer
    SEESUO boasts rich R&D experienceand top-notch production management
  • Customized production
    SEESUO provides tailored product design,development, and flexible manufacturing.
  • R&D cooperation
    SEESUO adapts swiftly to market changescollaborating with customers in R&D
PRODUCT PROBLEM
  • What advantages does the 8 Cores Patch Panel offer for future-proofing network infrastructure?
    The 8 Cores Patch Panel is designed to accommodate evolving network demands, allowing for easy upgrades and expansions. Its capacity to support multiple connections ensures that it can adapt to future technologies and increased bandwidth requirements, making it a strategic investment for long-term use.
  • How does the 8 Cores Patch Panel facilitate troubleshooting and network management?
    The organized port layout of the 8 Cores Patch Panel simplifies troubleshooting by providing clear visibility of connections. This design helps technicians quickly identify issues, manage network performance effectively, and reduce downtime, leading to more efficient network operations.
  • What environmental factors does the 8 Cores Patch Panel withstand to ensure reliability?
    Constructed with high-quality materials, the 8 Cores Patch Panel is engineered to endure various environmental conditions, such as temperature fluctuations and humidity. This resilience ensures consistent performance and longevity, making it suitable for demanding environments like data centers and telecommunication hubs.
